Standard Provisions:

• Stainless steel – 304, 320 or 316 glossy, satin finish,
• Steel – powder coated (Choice of RAL colors)

Other designs on request,

Customized design by arrangement

▲TOP

1. Servo positioning drive moves the tripod gently into the next rest position.
2. If user attempt to pass it before access is granted, the up-right bar will move about 5 degree to release the passing force of the user so that the user will not be hurt by his negligence or by the failure of card access system. Afterward, the up-right bar will move back to it’s home position.
3. Access memory, the system has a memory so that when access is granted to a user, another user can present his card to the card access control system before the first user pass the turnstile. This shorten the line up time and will not cause any problem to the normal anti-pass back function of most access control system (if the turnstile does not has memory, access signal which is granted before the first user pass the turnstile will make the 2^nd user not possible to pass the turnstile because the access control system will deny the access request of the 2^nd user who present his card to the reader again after the pass of the 1^st user.
4. Collapsible arm, it provide totally unblock passage to users who are in panic (e.g. Fire alarm, toxic gas attack). In traditional fix arm free wheel solution, the 2^nd user will be so close to the 1^st user in panic situation that the arm coming up may be block by the 2^nd user so that both the 1^st user and 2^nd user cannot pass the turnstile.
5. Auto-reload, security will be maintain once alarm is over. There is no need to send a security personnel to go to each individual turnstile to reset the bars.
6. Full Functions, for both in and out control, access indicator, fault indicator, RS232 port for direct connection with building automatic system, access control system, field programmable.
7. Can be up-graded to a system with Random generator for effective searching of employee (if security guard is authorized to search employee that they pick up, the guard will not possible to conduct a effective search on everyone, if he pick up individual for detail search, he will not pick up high ranking employee and those low ranking employee will think that the guard is pinpointing them or they themselves is like a criminal (all of these aversively affect employee relationship). However, a machine generate search request eliminate all these problems.
8. Locking opens even under pressure (does not jam when force applied to barrier rails)
9. Teeth brake ensure that locking is effectively done when it has to be locked.
10. A lot of design and custom design available.
11. Durable product from Germany.

▲TOP

1. Entry Direction
   ．Free, or
   ．Block, (Locked), or
   . Electrically controlled (e.g. By access control system or by amanual switch at the guard post)

2. Exit Direction
   ．Free, or
   ．Block (Locked), or
   ．Electrically controlled (e.g. By access control system or by a manual switch at
      the guard post)

3. Teeth Brake
   ．Solid locking is possible at any turning angle of the turnstile
   ．Very reliable locking

4. Buffer rotate
   ．The bar can move about 5 degree even access control signal has not been granted.
      This prevent the user from being hurt. Afterward, the bar will move back automatically
      to it’s home position

5. Time out
   ．if no one pass through, release is cancelled again after an adjustable period.

6. Servo position Drive
   ．Move the bar gently to the next position when the user lightly tough the bar
      (will never hurt the user),
   ．if an electronic sensor (e.g., light beam, pressure mat) the bar can start turning
      even the user has not touch the bar)

7. Programmable random generator for searching (optional)

▲TOP

1. Compatible with access control systems standards,
2. Serial interfaces prepared for fieldbus cross linkage
3. Special interfaces, signal exchange with building services automation and connection of customer’s operating elements available on request.
4. Coin box interface possible.

▲TOP

1. In the event of power Failure
   ．Arm collapse
   ．both directions free (non-drop arm models)

2. When power restore
   ．automatic resetting
   ．as an option, resetting after confirmation by push button control (e.g.. In
      connection with control desk or console, see options)

▲TOP

1. addition or installation of card readers, coin machine etc
2. signal equipment
3. random check generator (usually not needed for commercial revolving door)
4. control console for remote control (release, block and reject)
5. emergency power supply
6. railing elements for flow guidance
7. small gate matching the railing elements
8. counting mechanisms
9. weather protection (for open air installations)

▲TOP

1. On finished floor level (FFL)
2. On structural slab (SFL)

▲TOP


Press here for drawings of difference model
Customer require dimension is possible

▲TOP

Elevation : Skylight - Basic
  << CLICK FOR DETAILED PICTURE

Plan : Skylight - Basic
  << CLICK FOR DETAILED PICTURE

Side View : Skylight - Model Classic
  << CLICK FOR DETAILED PICTURE

Plan : Skylight - Model Classic
  << CLICK FOR DETAILED PICTURE

Elevation : Skylight - Plus
  << CLICK FOR DETAILED PICTURE

Plan : Skylight - Plus
  << CLICK FOR DETAILED PICTURE

Elevation : Skylight - Maxi
  << CLICK FOR DETAILED PICTURE
  << CLICK FOR DETAILED PICTURE

Plan : Skylight - Maxi
  << CLICK FOR DETAILED PICTURE
